How to Install Toilet Plumbing: A Step-by-Step Guide

Installing toilet plumbing is a task that many homeowners can handle themselves with the right tools and guidance. Whether you’re replacing an old toilet or setting up a new one in a renovation, this comprehensive guide will walk you through the process from start to finish. While this is a DIY-friendly project, always consider your comfort level and consult a professional plumber if needed.

Tools and Materials Needed

Before you begin, gather the necessary tools and materials to ensure a smooth installation process.

Tools:

Adjustable wrenches
Screwdriver
Drill with bits
Hacksaw (if necessary)
Tape measure
Bucket or shallow pan (to catch water)
Emery cloth (for cleaning pipes)

Materials:

New toilet (bowl and tank)
Wax toilet ring
Closet flange
Closet bolts
Shutoff valve
Stainless-steel water supply line
PVC pipe and fittings (if needed)
Silicone caulk (optional for sealing)

With these tools and materials on hand, you’re ready to start the installation.

Step-by-Step Installation

1. Turn Off the Water Supply

The first step in installing toilet plumbing is to turn off the water supply. Locate the shutoff valve near the toilet, usually found on the wall or floor behind the toilet. Turn it clockwise to shut off the water. If there’s no valve, you may need to turn off the main water supply for your home.

2. Remove the Old Toilet (if applicable)

If you’re replacing an existing toilet, you’ll need to remove it before installing the new one.

Disconnect the water supply line from the toilet tank by unscrewing it with an adjustable wrench.
Unscrew the nuts securing the toilet to the floor. These nuts are located at the base of the toilet on either side.
Gently rock the toilet back and forth to break the wax seal between the toilet and the closet flange. Once the seal is broken, lift the toilet off and place it aside.
Tip: Place an old towel or cloth over the open drain to prevent any sewer gases from entering your home while you work.

3. Prepare the Area

With the old toilet removed, take the time to inspect and prepare the area for the new installation.

Inspect the closet flange (the pipe fitting on the floor). If it’s damaged or corroded, replace it with a new one. The closet flange is critical for securing the toilet to the floor and ensuring a proper seal.
Clean the area around the flange, removing any old wax ring residue. Use an emery cloth to clean the flange and surrounding pipes.

4. Install the Closet Flange

If you need to replace the closet flange, this is the time to do it.

Glue the new closet flange onto the drainpipe using PVC primer and cement. Ensure the flange is level with the floor to avoid tilting the toilet.
Secure the flange to the floor with screws, making sure it’s tightly fixed and won’t move during the installation.

5. Position the Wax Ring

The wax ring is crucial for creating a watertight seal between the toilet and the drain.

Place the new wax ring on the closet flange, ensuring it’s centred. Some wax rings come with a plastic horn for better alignment.
Check the orientation: If the wax ring has a sloped edge, the narrow side should touch the flange.

6. Set the Toilet Bowl

Now it’s time to position the toilet bowl onto the flange.

Carefully lower the toilet bowl onto the wax ring, aligning the holes in the base of the toilet with the closet bolts protruding from the flange.
Press down firmly on the toilet bowl to compress the wax ring and create a secure seal. This step is critical for preventing leaks.

7. Secure the Toilet

Once the bowl is in place, it’s time to secure it to the floor.

Place washers and nuts onto the closet bolts and tighten them alternately with an adjustable wrench. Be careful not to overtighten, as this can crack the porcelain of the toilet bowl.
Tip: After tightening, sit on the toilet to help it settle into place, then check and re-tighten the nuts if necessary.

8. Attach the Toilet Tank

Next, you’ll attach the toilet tank to the bowl.

Place the rubber gasket on the underside of the tank around the flush valve.
Lower the tank onto the bowl, aligning the bolt holes.
Secure the tank to the bowl by inserting bolts through the holes and tightening the nuts underneath. Make sure the tank is level and securely fastened.

9. Install the Fill Valve and Flush Mechanism

With the tank in place, it’s time to install the fill valve and flush mechanism.

Follow the manufacturer’s instructions to install the fill valve and flush mechanism inside the tank.
Attach the flapper chain to the flush lever, ensuring it has the proper tension to operate smoothly.

10. Connect the Water Supply

With the toilet assembly complete, the final step is to connect the water supply.

Attach the stainless-steel water supply line to the fill valve at the base of the tank.
Connect the other end of the supply line to the shutoff valve. Use plumber’s tape on the threads to ensure a leak-free connection.

11. Test for Leaks

Turn the water supply back on and allow the tank to fill. As the tank fills, check for leaks around the connections and the base of the toilet.

Inspect the base of the toilet to ensure no water is seeping out from the wax seal.
Check all connections to make sure they’re tight and leak-free.

12. Seal the Base (Optional)

For a cleaner look and to prevent water from seeping underneath the toilet, you can apply silicone caulk around the base of the toilet.

Apply a bead of silicone caulk around the base of the toilet where it meets the floor.
Smooth the caulk with your finger or a caulking tool for a neat finish.

Conclusion

Installing toilet plumbing is a manageable DIY project that can save you money and give you the satisfaction of completing a home improvement task. By following these steps and using the right tools and materials, you can successfully replace or install a toilet in your home. However, always refer to the specific instructions provided with your toilet for any additional steps or manufacturer recommendations.

If you encounter any issues during the installation or if you’re unsure about any part of the process, it’s advisable to consult a professional plumber. Proper installation is crucial to avoid leaks and ensure the long-term functionality of your new toilet.

Need help with your plumbing installation? Contact our professional plumbers today for expert assistance and ensure your toilet is installed correctly and efficiently.

‍

Frequently Asked Questions

1. How long does it take to install a new toilet?

Installing a new toilet typically takes between 1 to 2 hours, depending on your experience and the condition of the existing plumbing. The process may take longer if you need to replace the closet flange or make additional repairs.

2. Can I install a toilet without a wax ring?

While wax rings are the traditional choice, you can use a rubber or foam gasket as an alternative. These gaskets are designed to provide a watertight seal without the mess of wax and can be easier to install.

3. What should I do if my toilet is still leaking after installation?

If your toilet is leaking after installation, check the tightness of the bolts securing the bowl to the floor and the connections to the water supply. If the leak persists, it may be due to a faulty wax ring or an issue with the fill valve. In such cases, consulting a professional plumber is recommended.
